Hospital Appointments

Hospital Appointments

Phone appointment booking for a hospital, on the Telenow app platform.

One AI receptionist answers the line, looks the caller up by number, and books, reschedules or cancels against real availability — in Hindi or English, whichever the caller speaks, though the CRM itself is always written in English underneath. Every change lands in the CRM immediately. A second, outbound agent can call a patient back about one specific appointment. A small three-page dashboard sits behind it for reception staff.

Zero hosting. Every tool is a declarative handler running on Telenow's own runtime — there is no server to deploy and nothing that can be down at 2am.

What it is

The call

"May I have your mobile number?"
        │
   find_patient(phone)  +  find_appointment(phone, scheduled)
        │
   ┌────┴──────────────────┬──────────────────────────┐
   │ known, has a booking  │ known, nothing booked    │ not on the system
   │                       │                          │
   ├─ book another ──┐     │ "Hello Asha — I can see  ├─ name, DOB, region
   ├─ reschedule ────┤     │  you last saw Dr Rao"    │
   ├─ cancel         │     │                          │
   └─ hear details   │     │ (no re-registration)     │
                     ▼     ▼                          ▼
              list_doctors  →  find_available_slots
                     │                │
              clash? offer alternatives, or change doctor
                     │
              read the summary back → explicit yes
                     │
              create_patient (if new) + book_appointment
                     │
              read back the reference → CRM updated

The 9 tools

Call-back: a human dial-out, and a second AI agent

The Patients and Appointments pages both carry two buttons per row:

• Call opens the dashboard's own softphone, prefilled with the patient's number, for a hospital staff member to dial themselves. Needs the softphone:dial scope.
• Remind places a real outbound call from the Hospital Reminder Caller agent (manifest/reminder-agent.mjs) — it reads the patient their appointment and can reschedule or cancel it right there, using the exact same reschedule_appointment/cancel_appointment tools as the receptionist. Needs the calls:initiate scope, and the agent to have been built once from the Doctors page.

Both are genuine platform capabilities (telenow.softphone.dial / telenow.calls.initiate), not a "callback requested" flag — see AGENT.md for how the reminder-caller flow is put together and why it reuses reschedule_appointment for a post-cancel rebook rather than a second booking path.

Design decisions worth knowing

Availability is materialised, not calculated. A voice agent has no compute — object.query filters by equality on declared fields, returns 50 rows, and cannot sort. So "what's free on Tuesday with Dr Rao?" can only be answered deterministically if the answer already exists as rows. Each doctor's working pattern is expanded into slot rows, and find_available_slots becomes a lookup.

The cost, stated plainly: the diary is only as fresh as the last time the CRM was opened. Two things keep that honest. Past slots are expired on load, so a stale diary returns nothing rather than yesterday's times — failing closed beats an agent offering an appointment that already happened. And the Doctors page shows exactly how much diary is left.

Booking is automated; cancelling is reconciled. Only a CREATE fires object.<type>.created on this platform — a PATCH and a DELETE fire nothing at all. So booking locks its slot via a workflow, instantly and server-side. Cancelling and rescheduling are updates, so no workflow can see them; the CRM frees those slots when it loads (reconcileSlots in ui/lib/slots.ts). Anyone opening the CRM fixes it for everyone, and genuine double-bookings are surfaced rather than silently resolved.

The caller is looked up as a person, not just as a booking. find_patient and find_appointment are separate calls because a patient seen last year with nothing booked has no appointment to find — but is very much an existing patient. Searching appointments alone would ask them for their name and date of birth all over again and create a second record for them, splitting their history and making the next lookup ambiguous. Visit history lives denormalised on the patient row (last_visit_date, last_doctor_name, visit_count) because object.query cannot sort, count or aggregate: the agent has no way to work out "when did I last come in?" from raw appointment rows mid-call, so the answer is written when it changes and simply read back.

The booking reference is pre-minted on the slot. An LLM asked to invent a unique code will collide with an existing one eventually, and two patients sharing a reference is unrecoverable over the phone. Every slot carries a booking_code; the agent copies it onto the appointment as ref.

Never use window.confirm / window.prompt / window.alert in this app. The dashboard renders every app inside a sandboxed iframe, and native browser dialogs are blocked there unless the sandbox carries allow-modals — which it does not. The failure is silent: confirm() returns false and prompt() returns null without showing anything, so if (!confirm(...)) return simply never proceeds and the button looks dead. Worse, it works under npm run dev, because the harness runs top-level rather than in an iframe — so this class of bug survives local testing completely. Use useConfirm() from ui/components/ui.tsx instead; it renders a real in-page dialog and supports an optional text field for things like a cancellation reason.

The agent writes the country code, because nothing downstream can. Patients say ten digits and should never be asked for a +91. But the agent's tools are declarative object.create / object.query handlers: the runtime stores exactly what the model sends and matches by exact string equality, with no normalisation step anywhere. A patient registered as 9876500001 is therefore invisible to the next lookup for +919876500001. So the agent is told — in the standing rules, on the greet node, and on every phone parameter it fills — to write every number as exactly +91 plus the ten digits, and nothing else. One form with zero branches, because a rule with an exception ("keep a foreign code if they said one") is a branch the model will eventually take wrongly mid-call. Because an instruction is not a guarantee, healPhoneNumbers in ui/lib/heal.ts rewrites anything already stored the wrong way when the CRM loads, patients and appointments together so the two never come unlinked.

The CRM never stores Hindi, even though the agent speaks it. A caller may talk in Hindi, English, or a mix, and the agent mirrors whichever they use. But every value written into a tool call — a name, a region, a reason — is translated into English first, and the same rule applies to searching: the agent translates what it heard before calling find_patient, rather than matching on the caller's own words. This is what stops the obvious failure mode of an agent that stores a name in Devanagari and then can't find that same patient on the next call because it's now searching in English. doctor.department gets the analogous fix on the CRM side: it is picked from a managed catalog (the department object) rather than typed free text, so it can't drift into two spellings of the same department across doctors.

Testing the UI without a dashboard

npm run dev

A working hospital at http://localhost:5174 — no Telenow account, no install, no phone number. Four doctors, a fortnight of diary, ~126 appointments, all dated from the day you run it. That is why telenow.dev.json is generated rather than committed: a static fixture is correct for one day and then shows an empty hospital, which reads as a bug in the app.

The harness adds three things createMockBridge does not provide:

• The design system. --tn-* variables and .tn-* classes are injected by the dashboard; standalone the CRM would render as unstyled HTML. A faithful stand-in plus a light/dark toggle. Treat colour and spacing as approximate and confirm in Dev preview.
• Realtime. The mock's data.subscribe is a no-op, so nothing re-lists after a write and the UI looks frozen.
• Fixture sync. The mock seeds localStorage once and ignores the file forever after. A stamp makes npm run mock take effect automatically.

Bottom-right: light / dark, and reset data.

telenow dev reads telenow.dev.json once, at startup, and embeds it in the page. So running npm run mock while the server is up changes nothing on screen — restart the dev server to pick up new fixtures. npm run dev does both in the right order.

None of this ships. npm run dev generates a manifest whose ui.entry points at ui/dev/index.tsx; npm run build always regenerates with the real entry. Excluded by construction, not guarded by a runtime flag.

For real data use the dashboard's Dev preview and paste the localhost URL — but every bridge call there is a real write against the installing organisation, so use a test org.

Development

npm run manifest    # compose telenow.app.json from manifest/ and lint it
npm run mock        # regenerate telenow.dev.json, dated from today
npm test            # 46 mutation tests proving the linter catches real bugs
npm run typecheck   # tsc over the UI
npm run dev         # standalone hospital with mock data
npm run build       # validate, bundle, zip

The linter in scripts/lint-manifest.mjs is deliberately stricter than telenow validate, which checks only a subset. Every rule targets a failure mode that passes validation, uploads cleanly, and then breaks silently on a live call — a flow whose start node does not exist (the agent quietly degrades to single-context), an equation edge missing its {} braces (parses false, never fires), an object.update matching an undeclared field, an icon off the whitelist. npm test corrupts the manifest 46 ways and asserts each rule fires, because a linter nobody has seen fail is indistinguishable from one that returns nothing.

manifest/
  index.mjs         app id, scopes, assembly
  objects.mjs       the 5 objects
  tools.mjs         the 9 tools
  agent.mjs         the receptionist's flow graph + SHARED_PATIENT_RULES
  reminder-agent.mjs  the outbound reminder caller's flow graph
  automation.mjs    the slot-locking workflow
  settings.mjs      per-install settings
  ui.mjs            the 3 pages
ui/
  pages/            Appointments · Patients · Doctors
  lib/slots.ts      generate, expire, reconcile
  lib/heal.ts       rewrite non-canonical phone numbers on load
  dev/              harness — never bundled into a release
scripts/
  build-manifest.mjs · build-fixtures.mjs · lint-manifest.mjs · lint.test.mjs

Changing the app id (it is global and first-come, so upload can 409):

npm run set-app-id -- your-new-id

Do not edit it by hand — the id also appears inside flow tool nodes, and a mismatch means the node is silently stripped at install.
